Laser NIR 40X
Laser specific applications for reproductive sperm analysis
Laser specific applications for reproductive sperm analysis
放大倍数 Magnification | 规格型号 Model | 数值孔径 NA | 工作距离 WD(mm) | 焦距 f’ (mm) | 分辨率 R (μm) | 焦深 DF (μm) | 物方视场 on object (mm) | 像方视场 on image (mm) | 螺纹尺寸 Screw |
40x | DZ40XNA05 | 0.50 | 3.67 | 5.0 | 0.45 | 0.59 | 5.5 | 22.0 | 0.8” |
