型号 | 传感器型号/尺寸 | 像素(μm) | G光灵敏度
动态范围
信噪比 | FPS/分辨率 | 合并模式 | 曝光时间 |
DCMOS14000KPA
DCM1400 | 14M/MT9F002(C) 1/2.3"(5.73x4.60) | 1.4x1.4 | 0.724v/lux-sec
65.3dB
35.5dB | 1.8@4096x3288
10@2048x1644
27@1024x822 | 1x1,2x2,4x4 | 0.4ms~2000ms |
DCMOS10000KPA DCM1000
| 10M/MT9J003(C) 1/2.3"(5.98x4.59) | 1.67x1.67 | 0.31v/lux-sec
65.2dB
34dB | 1.9@3584x2748
8@1792x1374
27@896x684 | 1x1,2x2,4x4 | 0.4ms~2000ms |
DCMOS09000KPB DCM900
| 9.0M/Special(C) 1/2.4"(5.83x4.37) | 1.67x1.67 | 0.31v/lux-sec
65.2dB
34dB | 1.9@3488x2616
8@1744x1308
27@872x654 | 1x1,2x2,4x4 | 0.4ms~2000ms |
DCMOS08000KPB DCM800
| 8.0M/Special(C) 1/2.5"(5.45x4.09) | 1.67x1.67 | 0.31v/lux-sec
65.2dB
34dB | 1.9@3264x2448
8@1600x1200
27@800x600 | 1x1,2x2,4x4 | 0.4ms~2000ms |
DCMOS05100KPA DCM510
| 5.1M/MT9P006(C) 1/2.5"(5.70x4.28) | 2.2x2.2 | 0.53 V/lux-sec
66.5dB
40.5dB | 5@2592x1944
18@1280x960
60@640x480 | 1x1,2x2,4x4 | 0.294ms~2000ms |
DCMOS03100KPA DCM310
| 3.1M/MT9T001(C) 1/2"(6.55x4.92) | 3.2x3.2 | 1.0 V/lux-sec
61dB
43dB | 8@2048x1536
22@1024x768
43@680x510 | 1x1,2x2,3x3 | 0.244ms~2000ms |
DCMOS02000KPB DCM200
| 2.0M/Special(C) 1/2.6"(5.12x3.84) | 3.2x3.2 | 1.0 V/lux-sec
61dB
43dB | 16@1600x1200
50@800x600 | 1x1,2x2 | 0.244ms~2000ms |
DCMOS01300KPA DCM130
| 1.3M/MT9M111(C) 1/3"(4.60x3.70) | 3.6x3.6 | 1.0V/lux-sec
71dB
44dB | 15@1280x1024
26@640x512
50@320x256 | 1x1,2x2,4x4 | 0.14ms~2000ms |
